Zangkejiang Bridge
牂牁江特大桥
Houchangxiang, Guizhou, China
(1,345) feet high / (410) meters high
3,543 foot span / 1,080 meter span
2024



One of China's most remote high level bridges, the Zangkejiang Bridge crosses a spectacular section of the Beipanjiang River gorge in Northwestern Guizhou Province along the Naqing Expressway between Nayong and Qinglong.

There is no waterway within Guizhou's borders with a greater collection of super-high bridge spans than the mighty Beipan River. Translated as the North Winding River, the BeipanJiang flows on a North-South rift that divides the Western and Eastern halves of Guizhou. The vertical limestone cliffs drop so deep that much of the river is in shadow during the day. Spaced every 50 kilometers along its length are a collection of epic road and railway bridges that have pushed the boundaries of China’s bridge engineering community. These include the 565 meter high Duge Bridge as well as the 300+ meter high Hukun and Guanxing suspension bridges as well as the Qinglong Railway arch.

The 1,080 meter span Beipanjiang crossing is the second longest of any bridge over the river after the Huajiang Bridge. The deck soars approximately 333 meters above the full level of the reservoir that was formed behind the Guangzhou Dam. The south tower measures 265 meters tall with 108.5 meters of that below the bottom of the truss.

The Naqing Expressway is home to some of China's most spectacular high bridges including the massive Liuzhi arch-beam viaduct and the Baishuihe and Azhihe arch bridges.



Zangkejiang Bridge Elevation









Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com







Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com



Image by Eric Sakowski / HighestBridges.com
























Zangkejiang Approaches.jpg




Zangkejiang Approaches 2.jpg





Zangkejiang Bridge satellite image.





Zangkejiang Bridge location map.
